BRAND:

Product code
DS-2CD2141G0-LIU(2.8mm)(South)

Stock Keeping Unit
CC400-7

Smart Hybrid
• Hikvision Smart Hybrid Light technology is a system that enhances low-light imaging in security cameras by offering three supplemental lighting modes: IR (infrared), white light, and a smart mode.
• This technology allows for both color and black and white imaging in low-light conditions, adapting to various environments and situations.

 Key Features

• High quality imaging with 4 MP resolution
• 1/3" Progressive Scan CMOS
• 2560 x 1440 Resolution
• 2.8mm Fixed focal lens
• Horizontal FOV: 98°, Vertical FOV: 54°, Diagonal FOV: 114°
• Up to 30m IR and White Light
• 850nm IR Wavelength
• Smart Hybrid Light: advanced technology with long range
• Built-in microphone for real-time audio security
• Efficient H.265+ compression technology
• 1x RJ45 10/100Mbps self-adaptive Ethernet port
• 12 VDC ± 25%, 0.5 A, max. 6 W, Ø5.5 mm coaxial power plug, reverse polarity protection ; PoE: IEEE 802.3af, Class 3, max. 7.5 W
• Water and dust resistant (IP67) and vandal resistant (IK08)

Note:
         Power supply is not included.

        IP67 rated products are waterproof.
        Meaning you can fully immerse them in water as deep as 1 meter for up to 30 minutes with no harmful effects.

DORI
• The DORI (detect, observe, recognize, identify) distance gives the general idea of the camera ability to distinguish persons or objects within its field of view.
• It is calculated based on the camera sensor specification and the criteria given by EN 62676-4: 2015

  DORI	Detect	Observe	Recognize	Identify
  Distance (2.8mm Lens)	63 m	25 m	12 m	6 m
